Описание
TP-Link Omada SX3032F - 32-портовый (32 x SFP+ 10 Gbps) L2 коммутатор уровня агрегации / ядра. Входит в экосистему Omada, поддерживая Zero-Touch Provisioning, централизованное облачное управление и мониторинг.
- Главная
- - Коммутаторы
- Коммутатор TP-Link Omada SX3032F
Коммутаторы
1/3
Коммутатор TP-Link Omada SX3032F
TP-Link
Код товара: 2485
10 021 550 сум
Характеристики
| Интерфейсы | 32 x SFP 10 Gbps 2 x USB-A 3.0 1 x RJ45 Console Port 1 x USB Type-C Console Port 1 x RJ45 Management Port |
| Пропускная способность | 640 Gbps |
| Таблица MAC-адресов | 128 K |
| QoS | Class of Service (8 Queues of Priority, Port Priority, IEEE 802.1p Priority, DSCP Priority, Queue Min-Bandwidth, Schedule Mode (SP, WRR, SP+WRR) Bandwidth Control (Rate Limit, Storm Control) Voice VLAN User-Defined OUI |
| Функции L2 и L2+ | Link Aggregation Spanning Tree Protocol Port-based and VLAN-based Loopback Detection 802.3x Flow Control Supports 2,048 IGMP groups ERPS Mirroring RSPAN MAC Address Table PIM-DM (IPv4) Multicast (IGMP Snooping, MLD Snooping, L2 Multicast Table, Fast Leave, Multicast VLAN Registration (MVR), Static Multicast IP, Multicast Filtering) |
| Дополнительные функции | Automatic Device Discovery Batch Configuration Batch Firmware Upgrading Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule |
| Функции ISP | 802.3ah Ethernet Link OAM L2PT (Layer 2 Protocol Tunneling) Device Link Detect Protocol (DLDP) DDM sFlow |
| VLAN | IEEE 802.1q Tag VLAN MAC VLAN Protocol VLAN VLAN VPN (QinQ) Private VLAN GARP/GVRP Voice VLAN Multicast VLAN Management VLAN |
| Security | Port Isolation CPU-Defend ARP Inspection (Dynamic ARP Inspection) DoS Defend IP-MAC-Port Binding (1,024 Entries, DHCP Snooping, ARP Inspection, IPv4 Source Guard) IPv6-MAC (Port Binding, 1,024 Entries, DHCPv6 Snooping, ND Detection, ND Snooping, IPv6 Source Guard) DHCP Filter Static/Dynamic Port Security (Up to 64 MAC addresses per port) Broadcast/Multicast/Unknown-unicast Storm Control (kbps/ratio control mode) 802.1X (Port base authentication, Mac base authentication, VLAN Assignment, MAB, Guest VLAN, RADIUS authentication and accountability support) AAA (including TACACS+) Secure web management through HTTPS with SSLv3/TLS 1.2 Secure Command Line Interface (CLI) management with SSHv2 IP/Port/MAC-based access control |
| Централизованное управление | Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller |
| Поддержка Zero-Touch Provisioning | есть |
